MRCOOL DIY 5th Gen E Star 9K BTU Single Zone Mini Split Complete System with 25ft Line Set 115V

MRCOOL DIY 5th Gen E Star 9K BTU Single Zone Mini Split Complete System with 25ft Line Set 115V

$2,329.00
Sale price  $2,329.00 Regular price  $2,820.00
Skip to product information
MRCOOL DIY 5th Gen E Star 9K BTU Single Zone Mini Split Complete System with 25ft Line Set 115V
1/2

MRCOOL DIY 5th Gen E Star 9K BTU Single Zone Mini Split Complete System with 25ft Line Set 115V

$2,329.00
Sale price  $2,329.00 Regular price  $2,820.00
DIY-09-HP-WM-115D25-O

Upgrade your home comfort with the MRCOOL 5th Generation DIY 9,000 BTU Single Zone Mini Split System, engineered for powerful heating and cooling in rooms between 200–350 square feet. Designed for homeowners who want professional-grade performance without expensive installation costs, this energy-efficient ductless mini split includes a 25-foot QuickConnect® line set and DIYPRO® cable for fast, tool-friendly installation. Enjoy year-round climate control with smart technology, whisper-quiet operation, and dependable performance backed by warranty protection.

Key Features & Benefits
  • Easy DIY Installation – Install your mini split system without specialized HVAC tools or professional experience. The included QuickConnect® line set comes pre-charged for a faster, simplified setup process.
  • 25-Foot QuickConnect® Line Set – Pre-filled with environmentally friendly R-454B refrigerant, eliminating the need for vacuuming or complicated charging procedures during installation.
  • Energy-Efficient R-454B Refrigerant – Designed with next-generation refrigerant technology that delivers improved efficiency and a lower Global Warming Potential (GWP) compared to traditional R-410A systems.
  • Durable DIYPRO® Cable – Eliminates the need for standard electrical conduit while providing enhanced protection against weather exposure, UV damage, and wildlife interference.
  • Smart Home Compatibility – Control your comfort from anywhere using the SmartHVAC app for iOS and Android devices, or connect with Amazon Alexa and Google Assistant for hands-free voice control.
  • Wireless Remote with Follow Me® Technology – The system automatically adjusts airflow and temperature based on the remote’s location for more accurate and personalized comfort.
  • Dry Mode Dehumidification – Reduce excess indoor humidity and improve overall air quality while maintaining a comfortable environment.
  • Gold Fin® Condenser Protection – Built with corrosion-resistant technology for enhanced durability and long-lasting performance, especially in coastal or humid climates.
  • Industry-Leading Warranty Protection – Includes a 7-year compressor coverage, and a 5-year parts warranty for long-term confidence and reliability.
  • Certified Safety & Reliability – Intertek listed (5031495) to meet rigorous performance, safety, and quality standards.

Perfect for bedrooms, offices, garages, additions, and small living spaces, the MRCOOL DIY 5th Gen 9K BTU Mini Split delivers efficient climate control, smart convenience, and reliable performance in one easy-to-install system.

Specifications
Dimensions & Weight
Condenser Dimensions 30.12 W" x 11.93 D" x 21.85 H"
Air Handler Dimensions 31.57 W" x 7.44 D" x 11.69 H"
Condenser Weight 65.48 lbs / 29.7 kg
Air Handler Weight 24.91 lbs / 11.3 kg
Capacity & Performance
Zone Capacity 1
Cooling Capacity 9,000 BTU
EER2 14
SEER2 23.6
Heating Capacity 10,000 BTU
HSPF2-4 11.5
HSPF2-5 8.6
Coverage Area 200 - 350 sq ft.
Outdoor Noise Level 54 dB(A)
Indoor Noise Level (Hi/Mi/Lo) 43.0/39.5/33.5/24.0/18.0 dB(A)
Electrical Requirements
Voltage 115V
Phase 1
Cycle 60 Hz
Max Fuse Breaker 20A
Min Circuit Ampacity 18A
Refrigerant & Piping
Refrigerant Type R-454B
Refrigerant Volume 30.34 oz
Liquid Line Size 1/4"
Suction Line Size 3/8"
Max Line Set Length 82 ft.
Features
Inverter DC
Compressor Type Rotary
Fan Only Option Yes
Quiet Mode Yes
Auto Cool Yes
Wifi Compatibility Yes
App Compatibility Yes
Works with IOS Yes
Works with Android Yes
Remote Control Included Yes

Certifications & Warranty

Certifications UL Listed, ETL Listed, Energy Star Certified, AHRI Certified
Warranty 7 Years Compressor
5 Years Parts

Information & Guides

Installation Manual

Brochure

Service Manual

Remote Manual

Accessory Manual

Warranty

AHRI Cert

Energy Guide
